Category I: explosive materials and articles
(No.1)
The 1.1, 1.2 and 1.3 categories
Symbol (explosive bomb): black; background: orange; digital "1" is written at the bottom.
(no.1.4)
(no.1.5)
(no.1.6)
Category 1.4
Category 1.5
Category 1.6
Background color: orange yellow; number: black; digit height is about 30mm, font width is about 5mm.
(for 100mmx100mm's logo); the number "1" is written at the bottom corner.
* * the location of a dangerous category - if it is a secondary risk, leave it blank.
* the location of the loading group. If it is a sub hazard, leave it blank.
The second category: gas
(no.2.1)
Type 2.1 flammable gases
Symbol (flame): black or white; background: red; digital "2" is written at the bottom.
(no.2.2)
Type 2.2 non flammable, nontoxic gas
Symbol (cylinder): black or white; background: green; digital "2" is written at the bottom corner.
(no.2.3)
Category 2.3 toxic gases
Sign (skull and crossed bone stick): black; background: white; digital "2" is written at the bottom.
The third type: flammable liquid
(No.3)
Symbol (flame): black or white; background: red; digital "3" is written at the bottom.
Fourth types
(no.4.1)
(no.4.2)
Type 4.1 flammable solids
Type 4.2 easily spontaneous combustion materials
Symbol (flame): black;
Bottom color: white with seven vertical red strips;
The number "4" is written in the bottom corner
Symbol (flame): black;
Background: the white part is white and the lower part is red.
The number "4" is written in the bottom corner
(no.4.3)
Type 4.3 substance that releases flammable gases from water
Symbol (flame): black or white;
Bottom color: blue;
The number "4" is written in the bottom corner
Fifth types
(no.5.1)
(No.5.2)
Class 5.1 oxidizer (substance)
Class 5.2 organic peroxides
Sign (with flame on the circle): black; background: yellow;
The number "5.1" is written in the bottom corner
The number "5.2" is written in the bottom corner
Sixth types
(no.6.1)
Category 6.1 toxic substances
Sign (skull and crossed bone stick): black;
Bottom color: white; the number "6" is written in the bottom corner
(no.6.2)
Category 6.2 infectious substances
The lower part of the sign can be labeled as "infectious substance" (infectious substance).
"In the case of damage of leakage immediatey notify Public Health health"
(words "notify the public health organ immediately after injury or leakage")
Symbols (three crescent symbols overlap together in a circle) and text: black; background: white;
The number "6" is written in the bottom corner
The seventh category: radioactive material
(no.7a)
I class - white
Sign (Trifolium): black; background: white;
Text: (mandatory requirement), marked by black body in the lower part of the logo.
Radioactive (radioactivity) contents... (content name) activity... (intensity is...)
Following the word "radioactive", a vertical red short bar is marked on the back; the number "7" is written at the bottom corner.
(no.7b)
(no.7c)
II class - yellow
III class - yellow
Sign (Trifolium): black; base color: upper half yellow with white edge, and lower half white.
Text: (mandatory requirement), marked by black body in the lower part of the logo.
Radioactive (radioactivity) contents... (content name) activity... (intensity is...)
Mark transport index.. (transport index) in a black box.
Follow the label of "radioactivity"
Two vertical red short bars
Follow the label of "radioactivity"
Three vertical red short bars
The number "7" is written in the bottom corner
(no.7e)
Seventh types of fissure materials
Background: white; text (mandatory requirement), marked in bold on the upper part of the logo:
Fissile (fission) words:
Mark in a black box: criticality safety index... (critical safety index)
The number "7" is written in the bottom corner
The eighth type: corrosive substances
(No.8)
Symbols (liquid, coming out of two glass containers, eroding hands and metal): Black
Bottom color: upper part white, lower half black with white edge; digital "8" written at the bottom corner.
The ninth category: dangerous substances and articles of miscellaneous classes
(No.9)
Symbols (in the upper half have 7 vertical strips): black; background: white; number "9" written at the bottom.
